Description
Magnetic stirrers are often used in chemistry and biology. They are preferred over gear-driven motorized stirrers because they are quieter, more efficient, and have no moving external parts to break or wear out (other than the simple bar magnet itself). Because of its small size, a stirring bar is more easily cleaned and sterilized than other stirring devices. They do not require lubricants which could contaminate the reaction vessel and the product. They can be used inside hermetically closed vessels or systems, without the need for complicated rotary seals. Magnetic stirrers may also include a hot plate or some other means for heating the liquid.
Characteristic Features
- Very compact and simple to operate
- Digital Display temperature and speed, Heating temperature: Rt-380 Degree and mixing speed :100-1800 RPM
- Heat and corrosion resistant aluminium alloy housing for durability
- Ceramic coated aluminum heating plate for great heat distribution and corrosion resistance
- Specially designed housing prevents spill from damaging the electronic components inside
- Secondary heat insulation plate prevents heat loss and eliminates heat damage to electronic components
- Adjustable temperature and rotation speed.
Model | YR02936 |
Top Plate Dimension (mm) | 280 × 280 |
Heating Temperature Range ( ) | Ambient to 400 degree |
Temperature Control | PID control LED display when the machine works. |
Temperature Range | Ambient to 400 |
Top Material | black ceramic or white ceramic |
Temperature Display | |
Permissible Ambient Temperature | Ambient temperature at 40 degrees |
Voltage | 110 V – 240 V |
Power(w) | 450 W |
Motor Power | 16W, DC20V |
Temperature Accuracy | ±5 degree |
Stirring Flask Capacity (ml) | 50 – 15 000 |
Overall Dimensions (mm) ( L × W × H ) |
500 x 420 x 270 |
Packing Dimension (mm) | 550 x 450 x 290 |
Shipping Weight (kg) | 9.5 Kg |
Shell material | Superfine Metal |
